24V AC Unit RV Air Conditioner Mini Split 10238BTU with(Outdoor Unit, Indoor Unit), 950W Electric AC Unit 24V Truck Cab Air Conditioner Split, for Semi Motorhome Trucks Bus Trailers Camper Van

SpecificationsApplicable Models: Car (Cab Within 6㎡/64ft²)Color: Black, WhiteVoltage: 24VRated Power: 950WCondition: NewMaterial: Copper, Aluminium, ABSInstallation Position: Inside the Cab; Outside the CabRefrigerating Capacity: 1000W-3000W (3400-10238BTU)Refrigerant: R134A (400-450g/0.88-0.99lbs) (Not Included in the Package)Oil: 90ml-120ml/0.02-0.03gal POE68Speed Range: 1000-3000rpm Way of Use: Direct Replacement Number of Pieces: 2Outdoor Unit Size: 49*21*66cm/19.3*8.3*26inchIndoor Unit Size：49*33cm/19.3*13inchFits (As a Reference)For car (Cab Within 6㎡/64ft²).Package Included1* Air Conditioner Kit1* Remote ControlOther Accessories for AssemblyInstallation1.Remove the outer casing.2.Select the installation position and mark the punch position. (Select 5 installation points)3.Punch holes at the mark points. (Tool: an 8mm/0.3inch drill)4.Use a pull riveter to fix the pull rivet nut at the marked hole.5.Fixed the damping pad and sleeve at the marked points on the external machine.6.Fixed the external machine.7.Install the internal machine: install an expansion valve.8.Fixed internal machine mounting plate.9.Fixed the internal machine.10.3/8inch pipe (high-pressure pipe) connected to the condenser. 11.Connect internal and external machine wires and power cord.12.Connect internal and external pipes, and fixed the evaporation box.13.Connect internal and external wires.14.Install the drainage pipe.15.Vacuum for 15-20 minutes.16.Refill refrigerant (Pure R134a) 400-450g/0.88-0.99lbs.17.The power cord is connected to the battery.18.Install the outer casing.19.Winding tape to fix the internal and external machine connecting pipe and the internal and external machine connecting wire.20.The installation is complete. Notes1.We strongly recommended professional installation. Please contact us if you have any questions.2.Please allow the slight difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before ordering.

• [High Working Efficiency]This air conditioner has a powerful 950W output, a maximum speed of 3000rpm, and a cooling capacity of 1000W-3000W (3400-10238BTU). It is equipped with five adjustable air outlets (360° rotation) to bring you powerful cool air and create a more comfortable indoor environment.
• [Good Cooling Effect] The parking air conditioner is a kind of in-car air conditioner. It uses the on-board battery DC power supply (24V) to make the air conditioner run continuously to adjust and control the temperature, humidity, flow rate, and other parameters of the ambient air in the car, to fully meet the comfortable cooling needs of the truck driver.
• [Saving Energy] The parking air conditioner works with a truck battery without an engine. Meanwhile, it adopts digital frequency conversion and allows you to use the energy-saving mode when you sleep at night, saving you lots of energy.
• [Long Endurance] It can work continuously for about 6 to 8 hours on a full charge, which can meet your daily needs.
• [Application] It can be applied to vehicles with below 6 m³ pilothouse, such as trucks, motor homes, trailers, buses, heavy trucks, school buses, and other occasions.
